The Arctic Cat 150 4x2 is a youth transitional ATV that delivers full-sized fun, handling and performance in a mid-sized package. It’s built with the T-14 rider rating for riders 14 years and older.
The 150 4x2 is loaded with big features: The spirited 149cc, SOHC 4-stroke air-cooled engine is as rider-friendly as it is tough, with a fully automatic CVT transmission with Forward, Neutral and Reverse. Hydraulic rear disc brakes deliver full stopping power, while fully-enclosed shaft drive adds durability with no maintenance required.
Its steel-framed chassis features an A-frame front suspension and a swingarm rear suspension, both with 3.5 inches of travel with the front dampened by 5-position adjustable shocks to handle a range of operator sizes and riding styles. Front drum brakes with rear hydraulic disk brakes provide positive, self-cleaning stopping power in all conditions with zero adjustment.
Functional racks on the 4x2 model have a 25-lb. front capacity and 50-lb. rear rack capacity, while a digital instrument pod displays speedometer, odometer, trip meter, digital clock, coolant temperature, fuel gauge and indicator lights for neutral, reverse and high beam lights. Safety features include a governed top speed of 20 mph, but with the ability to reach 30 mph.
Leading Features
- 149cc, SOHC 4-stroke, single-cylinder, air-cooled engine and electric start
- Fully automatic CVT transmission with Forward and Reverse
- Shaft drive durability with zero maintenance
- Electric start with a recoil backup has consistent, hassle-free starting
- Adjustable five position preload front shocks with linkage-type adjustable preload rear
- 25-lb. carrying capacity on the front rack and 50 lbs. on the rear
- 300-lb. towing capacity
- Hand and foot operated disc brakes
- Digital speedometer and odometer
- Available in red
Specifications
Suspension
Front Suspension/Travel (Inches): Single A-arm/3.5
Rear Suspension/Travel (Inches): Swingarm/3.5
Ground Clearance (Inches): 7.5
Shocks: Coil-over
Front Tire/Size: Kenda Pathfinder 21.7-10
Rear Tire/Size: Kenda Pathfinder/22x10-10
Wheels: Powdercoated steel
Dimensions
Overall Size LxWxH (Inches): 69.9x37.4x40.9
Wheelbase (Inches): 43.9
Dry Weight (Lbs.): 386
Front/Rear Rack or Box Capacity (Lbs).: 25/50
Towing Capacity (Lbs.): 300
Hitch Type: Flat Plate with Hole
Instrumentation
Instrumentation: Digital
Lighting: Dual halogen headlight/Single rear taillight
Colors
Available Colors: Red
Engine
Type: SOHC, 4-stroke, 2-valve
Displacement (cc): 149
Cooling System: Air
Bore & Stroke (mm): 62x49.5
Alternator Capacity (Amps): 12.5
Fuel Capacity (Gallons): 2.3
Powertrain
Power Steering: NA
Transmission: Automatic CTV w/ Forward, Neutral and Reverse
Drive System: 2 WD
Brakes Front/Rear: Drum/hydraulic disc
Features
Racks: Front and rear steel racks
Safety Flag: Accessory
Seating: Single
